Product details
Important parameters
- Housing
- ABS
- Color
- Black
- Terminal form
- DIP
- Weight
- 4g
- Oscillation Frequency
- 3000Hz
- Operating Voltage
- 5.0V
- Rated Voltage
- 1-30V
- Current Consumption(Max.)(
- 5mA MAX
- Sound Pressure Level ( Min.)
- 90dB Min at 10cm
- Tone/Pulse Rate
- /
- Operating Temperature
- -20 ~ +90℃
- Storage Temperature
- -30 ~ +100℃
- Wave soldering conditions
- 245 ºC within 5 sec.
- Manual soldering conditions
- 350 ºC within 5 sec.
- Size
- 12.6X7.0mm
